- Производитель:
- Артикул:NX-PG0232-5
- 99
- Degree of protection (IP):IP20
- Digital input type:None
- Digital output type:Line driver (RS-422), NPN, Voltage pulse
- I/O connection type:MIL (plug not included)
- I/O system:NX I/O Bus
- Max. encoder input frequency:0 kHz
- Max. pulse output frequency:4000 kHz
- Number of I/O connectors:1
- Number of IOG (V-) terminals:3
- Number of IOV (V+) terminals:3
- Number of pulse output channels:2
- Product Depth (unpacked):89.8 mm
- Product Height (unpacked):100 mm
- Product Weight (unpacked):70 g
- Product Width (unpacked):30 mm
- Signal processing:Synchronous, Task period prioritized
- SIL according to IEC 61508:None
- Type of module:Pulse output
2 импульсных выхода линейного драйвера, NPN, 4 Mpps, 1 разъем MIL, ширина 12 мм
