- Производитель:
- Артикул:K6CM-VBMD-EIP
- 99
- Analysis method:Moving average, Vibration acceleration (RMS), Vibration velocity (RMS)
- Applicable motor type:Three phase induction motor (rated voltage 600 V max.)
- Application:Bearing damage, Load misalignment, Load unbalance, Obstacles and loose belt, Resonance, Rotor/stator issues
- Communication port(s):EtherNet/IP, MODBUS/TCP
- Frequency range vibration:0.01-10 kHz
- Mounting method:DIN rail
- Mounting position:Amplifier: panel, Controller: panel, Sensor: motor
- Number of digital outputs:3
- Output type:NPN, Transistor
- Product Depth (unpacked):91.9 mm
- Product Height (unpacked):90 mm
- Product Width (unpacked):45 mm
- Setup method:Free software
- Supply voltage AC:20.4-26.4 V
- Supply voltage DC:20.4-26.4 V
- User interface:Condition monitoring software tool, Front LED, LCD screen
Мониторинг состояния двигателя, переменный ток, 3-фазный, асинхронный двигатель, вибрация и усилитель; Температурная модель, 24 В переменного/постоянного тока, транзисторный выход управления, Push-in Plus, ЖК-дисплей, Ethernet IP
